Application

Synthetic mica tape shall be taped directly over the conductors or used as a superior flame barrier wrapped under the outer jacket and is a perfect fire resistant component in Cable Manufacturing.

Specifications

Thickness mm : 0.10---0.15(±0.015---0.02)
Total Weight g/m2 : 29---220(±10---15)
Synthetic Mica g/m2 : 80---160(±5---10)
Glass Content g/m2 : 33±3
Binder (Silicone) Content g/m2 : 16---26(±3---4)
Volatility % : <1%
Tensile Strength N/cm : >100
Thermal/Frame Barrier C° : 1200
Subzero Resistance C° : -50
Stiffness N/m: <25---65
Dielectric Strength KV/Lage : >1.1---1.65
Flexibility g f/50mm : 150~350
Thermal Conductivity W/m°C : 0,2-0,25

Special Note

We are also available to supply the different size according to the User's requirements.
